| AC input voltage range | AC100-240V |
| Inrush current (max) | 0.5A/230VAC; 1A/110VAC |
| Output Voltage | 12V/24V |
| Output Current | 5A/2.5A |
| Leakage Current | 3mA/230VAC |
| Ripple & Noise (max.) | <100mVp-p |
| Line Regulation | 1% |
| Load Regulation | 1% |
| Setup Time | 1500ms/230VAC |
| Short circuit protection | Auto recovery mode |
| Surge | 40A |
| Dielectric withstand voltage | I/P-O/P: 2000VAC I/P-GND:1500VAC O/P-GND:0.5KVAC |
| Operation temperature | -20℃~+50℃ |
| Operation Humidity | 20~90%RH |
| Safety standard | EN 61347-2-13 |
| Insulation |
I/P-O/P: >100M Ohms / 500VDC /25°C / 70%RH |
| Size | Iron:110*78*35mm (L*W*H) |
